Product Description
Type C Voltage and Current USB Tester - A Must For Testing Or Repairing Your Phones & TabletsAutomatically recognize PD protocol and Qualcomm QC3.0/4.0 protocol:
A perfect companion for anyone troubleshooting power/cable/charge issues
Allows you to monitor charging states of the batteries be charged.
How To Change The Language To English
Hold a button down when powering up, and the language will start changing, then release the button when the language you want is highlighted.
Specification
Bluetooth: Not Support
Product weight: 18g
Input voltage: 4.5-24V
Input current:0-3A
Capacity measurement range: 0-99999mAh
Energy measurement range: 0-99999mWh
Load impedance measurement range: 1.5Ω-9999.9Ω
Temperature Measurement Range: -10°C to 100°C/0°F to 200°F
Voltage curve range: 4.5V-24V
Voltage measurement resolution: 0.01V
Current measurement resolution: 0.001A
Voltage measurement accuracy: ±0.2%
Current measurement accuracy: ±0.8%
Time measurement range: 0-99 hours 59 minutes 59 seconds
Temperature measurement error: ±3°C/±6°F
Current curve range: 0-3A
Refresh rate: 2Hz
Product Size: 71.2 x 31.8 x 12.4mm
Display screen: 1.44 inch color LCD display
Package Including
1 * USB tester (no Bluetooth) + 1*USB C to USB C Cable(50cm)
Note: The package also includes one paper instruction with double sides. If you need to have the instruction in Electronic Version, please feel free to contact us and we will send it for your reference.
For energy-saving, the lights on the screen will go off after 30s.)
If the screen doesn't function while it's connected to the power supply, please flip the connector of the USB C Cable. If those steps don't resolve the problem, please reach out to us for Searching for our customer support online with your order ID.
Features
- 【MULTIFUNCTIONAL TOOL】: Support quick charger recognition; data wire resistance value testing; QC2.0/QC3.0, Voltage/Current/Power Detection; data store; cable impedance measurement. Allows you to check the charging performance of the output wall/car/solar panel chargers and USB charging cables. It can be also used to find the highest current of the Wireless Charger, and test capacity and electric energy of power bank.
- 【WIDE RANGE APPILCATION】: Widely used in the quality inspection of digital devices with Micro USB and Type C peripheral. Great for testing and getting real draw ratings on various chargers and equipment, such as PC/Laptop/Desktop Computer/Mobile Phone/Power Bank/Charger/Discharge Load/Car Charger/Cable. With this tester, you can see clearly what was happening when charging various USB devices, ranging from iPhones, to Tablets and batteries.
- 【BRIGHT COLOR DISPLAY INTERFACE】: 1. Measurement Main Interface 2. Quick Charge Identification Interface 3. Data Recording Interface 4. Wire Group Impedance Measurement Interface 5. Voltage Graphing Interface 6.Current Graphing Interface 7. Settings Interface. Voltage measuring range 4.5-24V; current measuring range 0-3A.
- 【UNBEATABLE DESIGN】: 1.44'' LCD display with screen display rotating function design; 4 operating buttons and 5 connected ports. Plug robust coating with the gold-plated USB contacts can resist scratch, stain and damage. (Note: If the screen doesn't function or turn on/off frequently while it's connected to the power supply, please flip the connector of the USB C Cable to confirm if it can work correctly. For energy-saving, the lights on the screen will go off after 30s.)
- Important Warm Reminder: The bundle contains a single-sided protocol design USB Tester (no Bluetooth) and a reversible 50cm ultra-durable nylon braided USB type C to Type C cable. AS the tester is the one sided protocol design, if the display does not light up, please try to flip the Type C cable and try again. Eversame Promise to stand behind our products and provide a hassle-free 24-month warranty in case of product defects and friendly customer service.
