AC Current Voltage Amperage Power Energy Panel Meter LCD Digital Display Ammeter Voltmeter Multimete

Product Description

A.Main Function 1. Electrical parameter measurement function (voltage, current, active power, energy, frequency, power factor) 2. Overload alarm function (over power alarm threshold, backlight and power flashing to alarm). 3. Power alarm threshold preset function (can set power alarm threshold). 4. The energy can be reset use the key. 5. Store data when power off. 6. Large-screen LCD 7. Backlight function. B. Appearance and Key function Display interface is large-screen LCD, it can display six parameters at the same time. 1. Power: test range: 0~22000W, Starting measure power: 0.5W 2. Energy: test range: 0~999kWh 3. Voltage: test range: 80~260V 4. Current: test range: 0~100A,Starting measure current: 0.02A 5. Frequency: test range: 45~65Hz 6. Power factor: test range: 0~1PF C.Specification parameters 1. Working voltage: 80 ~ 260VAC 2. Test voltage: 80 ~ 260VAC 3. Rated power: 100A/22000W 4. Operating frequency: 45-65Hz 5. Measurement accuracy: 1.0 grade

Features

• 1. Digital Multimeter:This power energy meter can measure and display voltage current active power energy frequency and power factor at the same time.with split current transformer,more convenient to install .
• 2. Overload Alarm function:Backlight and power will flash simultaneously to give an alarm when exceeding the preset value.You can preset power limit by yourself.
• 3. Automatic Data Storage Function:The last test data is stored automatically when the power supply abruptly lose. Don't worry about data loss due to sudden power outages.
• 4. One-touch Control:The button can be used to control the backlight,reset energy, preset power alarm limit.
• 5. LCD Display:Large-screen LCD with all sight 180° view,The blue backlight can be turned on/off manually. PZEM-022 requires an external power supply to light up the screen.
