3977393 Thermal Fuse 3977767 Dryer Thermostat 3392519 Dryer Thermal Fuse 3387134 for Whirlpool Kenmo

Product Description

A 3387134 cycling thermostat is in tune with the temperature of your dryer and regulates it in order to maintain a certain temperature. This thermostat reaches a temperature of 155 degrees, turns off, and then turns on again once it has dropped by 25 degrees. If your dryer is not giving off enough heat, is over-heating, is not turning on, or is having issues with the timer functionality, it could indicate an issue with the thermostat. The installation of the cycling thermostat is simple and the only tool required is a 1/4 inch nut driver (and gloves for safety).
This part fixes the following symptoms: No heat or not enough heat | Takes too long to dry | Will Not Start | Timer will not advance.

The 3392519 thermal fuse is used in dryers as a safety mechanism that stops the flow of electricity to the motor circuit when a dryer overheats. This replacement part features two 3/16 inch terminals, and is sold individually. When this fuse is faulty, your dryer will not start or it will not heat properly.

The 3977393 thermal cut-off turns off the heating component when the dryer overheats, ensuring there is a consistent level of heat at all times. If your dryer is not starting properly, shutting off too soon or is taking too long to dry your clothes it could be because it has blown and needs to be replaced.
This part fixes the following symptoms: No heat or not enough heat | Takes too long to dry | Will Not Start | Too hot

This 3977767 high-limit thermostat with Terminal Extension Arm acts as as safety mechanism that keeps the dryer from overheating. Once the dryer temperature reaches 221 degrees Fahrenheit, this piece will shut down power to the heating element until it drops by 80 degrees Fahrenheit.
This part fixes the following symptoms: No heat or not enough heat | Takes too long to dry | Too hot | Will Not Start

Features

• Dryer Thermal Fuse Exact Fit: ▶3387134 replaces number: wp3387134,306910, 3387135, 3387139, WP3387134VP; ▶3977767 replaces number : 3399693, 3977767, AP6009043, WP3977767VP; ▶3977393 replaces number：NP279816、3399848, PS334299, AP3094244, WP3977393 EAP334299; ▶3392519 replaces number: wp3392519,3388651694,511800-05, WP3392519VP. This dryer thermal fuse kit can solve the dryer failure and help protecting your dryer and promotes efficiency.
• High Quality & Durable: The dryer thermal fuse kit is made of high quality metal and plastic, which is well tested by the manufacturer to ensure meeting OEM standards. Ensure long-lasting and stable performance.
• Wide Compatibility: The sensor kit kit is made exactly fit for most top brands (Whirlpool, Kenmore, Maytag, KitchenAid, Roper,Crosley,Estate,Amana,Admiral). Figure 6 is Compatible Model. If you are not sure whether replacement parts are suitable, welcome to contact the Seller Support.
• Easy to install: Don’t spend hundreds of dollars to replace the dryer, what all you need is a kit of replacement parts. It is pretty easy to replace old dryer senors. After watching the repair video, you can do it by yourself!
• Quality Warranty: We promise excellent quality and we will continue to regard quality first, customer supreme, sincerely managing and hospitable service as principle to grow up with you.Will send replacement or refund regardless the reason if it fails.
