Product Description
Mini Auto Range LCD Digital Multimeter Voltmeter Tester Tool AC/DC Pocket XB866
Features:
100% quality and Brand new.
Display: LCD
MAX. Show Value: 1999 counts max Polarity Indication:"-" indicates negative polarity
Overrange Indication: Display" OL" or "-OL"
Sampling Time: approx.0.4second Until showing of function and electrical capacity
Specification:
Auto power supply: 15min
Power Supply: 1.5Vx2(Not included)
Temperature, Factor<0.1*Accuracy/ degree
Operating Temperature: 0 degree to 40 degree (32°F to 104 °F)
Storage Temperature: 0 degree to 50 degree (10°F to 122 °F)
Circumstance Temperature: 23±5 degree Relative Humidity:<70%
Auto Range:
DC Voltage: 200mV, 2V, 20V, 200V, 600V
AC Voltage: 2V, 20V, 200V, 500V (Frequency Range: 40~400Hz)
DC Current: 200uA, 2000uA, 20mA, 200mA
AC Current: (Take it only as reference) 200uA(±5% of rdg), 2000uA (±3% of rdg),
20mA (±5% of rdg), 200mA (±3% of rdg) (Frequency Range: 40~400Hz)
Resistance: 200Ω, 2KΩ, 20KΩ, 200KΩ, 2MΩ, 20MΩ
Diode Test: test current 1mA, test voltage 1.5V DC
Continuity: <80Ω Beeper
Size: 115x70x20mm
Quantity: 1 Pc
Note:
Please allow 1-3mm error due to manual measurement. pls make sure you do not mind before you bid
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
Package Contents:
1 x Mini LCD Digital Multimeter with 2 test leads
1 x User Manual
Features
- ✿ Streamline design and very portable.
- ✿ Overrange protection for all ranges
- ✿ It includes 7 function with 25 range.
- ✿ Max Voltage Between Terminals And Earth Ground; 600V DC or 500V AC
- ✿ Accuacy is specified for a period of year after calibration and at 18 degree to 28 degree with relative humidity to 75%
