Product Description
Description:WIFI Kit series is the new development of the cost-effective networking program, the main chip using Lexin ESP32, Tensilica LX6 dual-core processor, 240MHz, computing power up to 600DMIPS, chip built-in 520 KB SRAM, 802.11 b / g / N HT40 Wi-Fi transceiver, baseband, protocol stack and LWIP, integrated dual-mode Bluetooth (traditional Bluetooth and BLE low power Bluetooth).
Onboard 8MByte(64M-bit) Flash, Wi-Fi antenna, 0.96-inch blue OLED display, lithium battery charging circuit and interface, CP2102 USB to serial chip, the perfect support for Arduino development environment
Specification:
Operating voltage: 3.3V to 7V
Operating temperature range: -40 ° C to + 90 ° C
Data rate: 150 Mbps 11n HT40,72 Mbps 11n HT20,54 Mbps 11g, 11 Mbps 11b
Transmit power: 19.5 dBm 11b, 16.5 dBm 11g, 15.5 dBm 11n
Flash Size: 8MByte(64M-bit)
Module Size:50*25.4*10.3 mm
Lithium battery interface:2Pin-1.25mm interface
Receiver sensitivity up to - 98 dBm
UDP continues to throughput by 135 Mbps
Supports Sniffer, Station, softAP and Wi-Fi Direct modes
Package Including
1 * ESP32 Development Board with OLED
2 * Pin headers
Features
- Support Ard uino Development Environment: WiFi kit 32 is a classic IoT Dev-board, it’s a highly integrated development board based on ESP32 (including WiFi and BLE)
- Easy to Use: With good RF circuit and low-power design, ESP32 development board is the best choice for smart cities, farms, homes and IoT makers
- Perfect Circuit Design: Onboard WiFi, Bluetooth 2.4GHz PCB antenna. Integrated CP2102 USB to serial port chip, convenient for program downloading, debugging information printing
- Power Supply: Onboard SH1.25 battery interface, integrated lithium battery management system. You can also use the Type-C interface to power the development board, the interface with complete ESD protection, short circuit protection, RF shielding and other protection measures
- OLED Display: Onboard 0.96-inch 128*64 dot matrix OLED display, which can be used to display debugging information, battery power and other information
