100' Aluminum URD Dyke 2-2-2-4 Cable Direct Burial Quadruplex Secondary Wire

Product Description

Aluminum 600V URD cable is designed for use in secondary distribution circuits, where installed in duct or direct burial applications. Maximum operating temperature is not to exceed 90°C in wet and dry locations. Voltage rating is 600 volts. As an option, this cable can provided pre-pulled into duct. Aluminum URD Quadruplex Cable has a concentric strand or compressed 1350-H19 series aluminum conductor. Conductors are cabled together, with surface printing for identification. The neutral conductor has a yellow stripe.

Features

• Size AWG: 2
• Stranding: 7
• Insulation Thickness (mils): 60
• Neutral Size AWG: 4
• Single Phase Conductor Inches: 0.403
• O.D. Inches: 0.973
• Weight lbs./1000ft: 367 lbs
• Ampacity: Direct burial: 155 Amps
• Ampacity: In duct: 115 Amps
